NOVPEK™i.MX6Q/D

Flexible evaluation kit for NXP® i.MX 6Q and i.MX 6D SoCs to optimize performance and on-chip resources by providing access to all available I/Os.

The NOVPEK™i.MX6x Platform Evaluation Kit was developed with close collaboration with NXP® to give OEMs a flexible platform to evaluate i.MX 6 processors by giving an access to all the available I/Os on the device. The platform evaluation kit comes with software to help engineers get started quickly.

Features

  • 201 easily accessible IOMUX pins arranged in two 32x3 & one 16x3 100mil pin headers
  • Supports all dedicated i.MX6x peripherals: USBOTG, USB HOST, SATA, LVDS, PCIe, HDMI and MIPI/SDI
  • Wired Advanced Power Management (PM) development support
    • Add-On card
    • Multiple custom solutions available
    • Multiple voltage settings for each peripheral voltage rail
    • Accurate power consumption analysis framework for all voltage rails on the i.MX6x
  • On-board debug ports: JTAG and 16bit ETM-Bootable with terminal support
  • RS232 and TTL interfaces, only uses two i.MX6x pins
  • All i.MX6x boot options available
  • Simplified firmware/software development through 10/100 Ethernet port
    • SPI based
    • Does not consume the built-in FEC
  • USBOTG port that can be forced to HOST mode
  • Highly integrated power management solutions
    • Multiple power-on events
    • Reprogrammable for configurability

Kit Contents

  • Hardware
    • NOVSOM®i.MX6x Module
    • NOVPEK™i.MX6x Baseboard
    • One Power Management solution module
      • Dialog PMIC based module
      • Linear Technology based module
    • Power Supply
    • UART TTL to USB cable
  • Software and Documentation
    • SD card with Linux image and example code
    • QNX porting
    • Android porting
    • Quick Start Guide
    • Link to the portal with manuals, documentation, virtual machine and tools

Customization Services

NOVPEK™i.MX6x development board is meant for proof-of-concept testing. NovTech Design Services can help with customized production-ready systems with the following services:

  • Custom baseboard design or a single board solution
  • Optimize Linux drivers and software
  • Customize enclosure to match environmental requirements
  • Help with regulatory requirements
