NOVSOM®CVL
Low-cost System on Module based on Intel® Cyclone® V SoCs in 484 BGA packages with customizable DDR3 capacity and boot devices.
The NOVSOM®CVL provides a quick way to build a board based on an Intel® Cyclone® V SoC. It can be customized with specified DDR3 capacity and boot up devices. The use of NOVSOM® provides users with a proven small form factor module, eliminates the need for complete DDR3 memory routing or power solution design, and simplifies baseboard board layout. All users need to do is design a four to six layers boards with the required peripherals, and the Board to Board (B2B) connectors to support the NOVSOM®CVL.
- Intel® Cyclone® V SoC in 484 BGA package (U19)
- Dual Cortex®-A9 cores @ up to 925MHz
- Up to 110K LE logic
- Up to 1 GB DDR3
- Multiple on-board solid state storage/boot options (HPS)
- On-Board FPGA configuration device (QSPI)
- On-board clocks
- On-board power solution requiring a +5V power input
- All FPGA signals are routed to SODIMM 200 pin, 2V5 type (excluding HPS DDR3)
- Allows any voltage assignment to each I/O bank (VCCIO, VCCPD, VREF)
- Supports Linux, VXWorks, QNX OS
- Production ready
- Bootable microSD card slot
Customization Services
NovTech Design Services can help with customized production-ready systems with the following services:
- Custom baseboard design or a single board solution
- Optimize Linux drivers and software
- Customize enclosure to match environmental requirements
- Help with regulatory requirements
NovTech Design Services can help with customized production-ready systems with the following services:
- Custom baseboard design or a single board solution
- Optimize Linux drivers and software
- Customize enclosure to match environmental requirements
- Help with regulatory requirements
- NOVSOM®CVL Ordering Guide
- Contact NovTech for customization, pricing and availability.
