NOVSOM®COMeLS20xx

A COM Express® Type 7 in a Compact Form Factor for Fog/Edge Compute Node with built-in L2/L3 Switch, based on NXP® QorlQ® Layerscape LS204x/8x Arm® SoC.

NOVSOM®COMe7LS20xx System‐On‐Module (SoM) complies with COM Express® Type 7 specifications. It features NXP® QorlQ® Layerscape 2088A SoC with integrated octal 64-bit Arm® Cortex®‐A72 cores with packet processing acceleration and 16 high-speed channels. It brings to customers all the benefits of the SoC while accelerating the design of an application board by eliminating the need to develop the DDR interface, boot devices, clocks and power management solutions and interfaces PHYs. The use of NOVSOM®COMe7LS20xx provides users with a proven industry standard small form factor SoM allowing engineers to focus their design efforts on the required peripherals for their application.

Features

  • COM Express® Type 7 Compact form-factor
    • Full function pin-out (except NC-SI)
    • 16 SerDes lanes for Ethernet, PCIe and SATA I/O
  • NXP LS2088A/LS2048A with AIOP or NXP LS2084A/LS2044A (no AIOP)
    • 4 or 8 Arm®V8 Cortex®-A72 cores @ up to 2.0 GHz
    • DPAA2 data path acceleration with L2 switching
    • Networking and Crypto hardware offload
  • Two 64Bit DDR4 banks (max. 16 GB each)
  • 32Bit data path DDR4 bank (max. 2GB), supporting AIOP
  • Reconfigurable SerDes for Ethernet, PCIe and SATA
    • 4x 10G KR + 4x SGMII + 1x QSGMII Ethernet
    • 4x PCIe 3.0 controllers
    • 2x SATA ports
  • Up to 7 USB 3.0 ports
  • Boot from eMMC (max 64 GB), QSPI and baseboard QSPI
  • Support for secondary and recovery boot
  • Industrial operating temperature: -40°C to +85°C

Customization Services

NovTech Design Services can help with customized production-ready systems with the following services:

  • Custom baseboard design or a single board solution
  • Optimize Linux drivers and software
  • Customize enclosure to match environmental requirements
  • Help with regulatory requirements

Applications

  • Industry 4.0 Fog/Edge compute node
  • SDN/OpenFlow™ white box switching
  • Network function virtualization (NFV) solutions
  • Video Recorders, Surveillance
  • Wireless cell site routing
  • Security and Encryption

Kit Contents

  • Hardware
    • NOVSOM®COMeLS20xx Module
  • Software and Documentation
    • SD card with Linux image and example code
    • Quick Start Guide
    • Link to the portal with manuals, documentation, virtual machine and tools

Design Resources

  • Schematic
  • Assembly Drawings
  • Linux VM with all sources and tool-chain
  • Git server for latest code updates
  • Linux board support package (BSP) including NXP® Layerscape drivers for all Type 7 defined interfaces

Support Resources

Ordering Information

Contact NovTech for customization, pricing and availability.

Additional Resources

Register your NovTech product

Similar Products

NOVSOM®COMe7LS20xx System‐On‐Module (SoM) complies with COM Express® Type 7 specifications. It features NXP® QorlQ® Layerscape 2088A SoC with integrated octal 64-bit Arm® Cortex®‐A72 cores with packet processing acceleration and 16 high-speed channels. It brings to customers all the benefits of the SoC while accelerating the design of an application board by eliminating the need to develop the DDR interface, boot devices, clocks and power management solutions and interfaces PHYs. The use of NOVSOM®COMe7LS20xx provides users with a proven industry standard small form factor SoM allowing engineers to focus their design efforts on the required peripherals for their application.

NOVSOMCOMeLS20xx board image
